| Machine Specification | ||
| Model No | MSK-OM85P/MSK-OS85P | |
| Main features | 1, High Brightness LCD Module,Sunlight viewable | |
| 2, Special designed fan cooling system with high-quality fans | ||
| 3, All weatherproof dustproof enclosure, +6mm vandal-proof protective glass, +1.5mm SPCC | ||
| 4, Support HDMI VGA USB input, Non-network version, Android OS 5.1+, Windows OS 7/8/10, RS232 board optional | ||
| 5, Integrated with Light Sensor, auto Temperature Sensor, Alarm modules, more modules optional | ||
| 6, Adapt import Akesu paint powder from Germany, 5-7 years no fade, acid and alkali, professional anti-corrosion more than 5 years | ||
| 7, LCD protect function: Auto Shut off function upon internal temperature reaches 70℃ | ||
| 8, Integrated with Lightning protection, leakage protection switch, timer | ||
| 9, Adapt Taiwan Meanwell power, A/C 100-240V, 50/60Hz | ||
| 10, Easy maintenance enclosure plus built-in anti-theft locks | ||
| 11, Working temperature: -40℃ - 50℃ | ||
| 12, Different enclosures can be customized exactly according to client requirements | ||
| Panel | Panel type | LG a-Si LCD |
| Diagonal Aspect Ratio | 85" 16:9 | |
| Physical Resolution | 1920*1080 | |
| Color depth | 10bit(D), 1.07Billon colors | |
| Viewing Angle | H178º/ V178º | |
| Luminance(nits) | 1500CD/㎡ | |
| Contrast | 4000:1 | |
| Backlit type | LED | |
| Response time | 6ms | |
| Life(hrs) | More than 60000 | |
| Core Board | Android board | RK3288,Quad core CPU,8GB memory,HDMI VGA input USB port |
| Android board | RK3188,Dual core CPU,4GB memory,HDMI VGA input USB port | |
| Windows board | I3 CPU,4GB memory,500GB HDD,HDMI VGA ouput,USB,WiFi,RJ45 | |
| Windows board | I5 CPU,16GB memory,500GB HDD,HDMI VGA ouput,USB,WiFi,RJ45 | |
| Windows board | I7 CPU,16GB memory,500GB HDD,HDMI VGA ouput,USB,WiFi,RJ45 | |
| Windows license | Official Windows license | |
| Optional Terms | Nano Touch | 10dots Nano touch(standard) |
| Heating module | Support | |
| WiFi hotspot | WiFi hotspot module | |
| Normal built in Camera | Support | |
| Dome camera | Support | |
| Consumption | Power Supply | AC100~240V 50/60Hz |
| Standby/Max.Consumption | ≤ 3W/≤250W | |
| Cooling | Low Noise Fans | IP55 Grade Heating Module optional All weatherproof dustproof enclosure |
| Air Conditioner | IP65 Grade All weatherproof dustproof enclosure | |
| Working function &Environment | Control Method | Depends on above board selected |
| Color System Support | PAL/NTSC/SECAM | |
| OSD Language | English/Multiple Language | |
| Rich Resolution | Support 1080P,1080I,720P,480P &multiple resolutions | |
| Video format support | MPEG1/MPEG2/MPEG4/DIVX/ASP/WMV/AVI | |
| Image format support | JPEG/BMP/PNG/GIF | |
| Audio format support | WAV/MP3/WMA/AAC | |
| Splicing Display | Support | |
| Working Temperature | 0℃-50℃ | |
| Working Humidity | -40%-55% | |
| Storage Temperature | 0℃-50℃ | |
| Storage Humidity | 5%-95% | |
| Appearance &packing | Application Condition | Pure outdoor all weatherproof |
| Material | Cold-roll steel SPCC | |
| Frame Color | Black/White/Silver/Red/Gray/Customization | |
| Installation type | Wall Mounted/Floor Standing with fasten on ground | |
| Packing way | Safe packing with bubble foam, in wooden case | |
| Quality Standard | ISO9001,CE,ROHS,FCC,CCC | |
| Payment Terms &Conditions | ||
| 1.Payment term:Alibaba Trade Assurance T/T. | ||
| 2.Leading time: Standard sample: 6working days; Standard bulk 100pcs: 22working days;Cutomized sample:25-30days,bulk: >=30days | ||
| 3.Aboved price is based on FOB Shenzhen and standard design.Photos are reference only,actual maybe different. | ||
| 4.Warranty:standard 1year warranty,extra fee will be charged for additional years warranty. | ||
