| Panel Specifications | |
| LCD Technology | A-Si TFT-LCD |
| Active Screen Diagonal | 55 inch |
| Active Display Area(WxH) | 1209.6×680.4MM |
| Panel Dimension(WxHxD) | 1213.5×684.3×61MM |
| Total Bezel Width | 3.5mm |
| Aspect Ratio | 16:9 |
| Physical Resolution | 1920*1080 |
| Backlight System | LED |
| Luminance(nits) | 500cd/㎡ |
| Contrast | 1200:1 (typ.) |
| Viewing Angle | H 178°|V 178° |
| Display Colors | 8Bit,16.7M |
| Refresh Rate | 60Hz |
| Response Time | <=6ms |
| Life(hrs) | >60,000(hrs) |
| MTBF | > 100,000 h |
| Surface | Anti-glare |
| Standby Power Consumption | <3W |
| Maximum Power Consumption | ≦200W |
| Power Supply | AC100~240V 50/60 HZ |
| Cooling | Low noise fans |
| Heat Dissipation | 819 BTU/h (max) |
| Working Time Capacity | 7x24x365hours |
| Application Area | Indoor/Semi Outdoor |
| Working Temperature | 0℃～50℃ |
| Working Humidity | 0.85 |
| Storage Temperature | -20-60°C | -4-140°F |
| Storage Humidity | 85% non-condensing |
| Controller Inputs, Outputs &Features | |
| DVI-I DUAL LINK | 1 |
| HDMI | 1 |
| VGA | 1 |
| CVBS IN | 1 |
| CVBS OUT | 1 |
| RS232 IN | 1 |
| RS232 OUT | 1 |
| ISP IN | 1 |
| IR IN | 1 |
| CODING BUTTON | 1 |
| AC IN | AC100-240V |
| Color System Support | PAL/NTSC/SECAM |
| Control Type | IR Remote &Software Control |
| Menu Language | English/Chinese(Multiple Language can be customized) |
| Vertical/Horizontal Display | Support |
| Combine Display | Support combine any horizental &vertical numbers of screens and show display |
| Support combine all screens together to show 1image | |
| Multiple Interfaces | Support DVI,HDMI,VGA,AV &multiple signal inputs |
| Rich Resolution | Support 1080P,1080I,720P,480P &multiple resolution inputs |
| Appearance | |
| Standard Packing | Standard Full Wood Box Pallet |
| Weight | 25kg |
| Quality Standard | ISO9001,CCC,RoHS,FCC |
| Payment Terms &Conditions | |
| 1.Payment term: Alibaba trade assurance,Leading time 3-5working days. | |
| 2.Aboved price is based on FOB Shenzhen and standard design.Photos are reference only,actual maybe different. | |
| 3.Warranty:standard 1year warranty,extra fee will be charged for additional years warranty. | |
